Pioneer 42" & 61" Plasma parts & board assy interchageability list
A
pplicable models: PDP4214HD, PDP42A3HD, PRO1410HD, PDP614MX, PDP6100HD, PDP424MV
Part description Latest Part # Old part #
PDP4214HD
PDP42A3HD
PDP6100HD
PRO1410HD
PDP614MX PDP424MV
Remarks
Data Relay Board (Left Down) 9S899895 (Ver 02A) X X
Data Relay Board (Right Down) 9S899896 (Ver 02A) X X
Data Relay Board (Left Up) 9S899893 (Ver 02A) X X
Data Relay Board (Right Up) 9S899894 (Ver 02A) X X
Signal relay PKG (lower center) 9S899762 9S899587 X X X
Signal relay PKG (lower left) 9S899586 X X X
Signal relay PKG (lower right) 9S899589 X X X
Signal relay PKG (upper center) 9S899760 9S899584 X X X
Signal relay PKG (upper left) 9S899583 X X X
Signal relay PKG (upper right) 9S899761 9S899585 X X X
Signal relay PKG (left) 9S899524 X
Signal relay PKG (right) 9S899525 X
PDP Optical Filter 05100-0020 X X
Filter 29KS0271 29KS0171 X X X
29KS0121 X
Fan 10511-07-001 X X
3S170014 X X X Left & Middle (from rear)
3S170015 X X X Right (from rear)
Audio PWB Ass
y
937J8SH3 937J8SH1 X
937J9SH3 937J9SH1 X
937J9SH4 X
937F0SH4 937F7SH2 X
Sub AV & AMP Ass
y
220-2050 X X
Sub Key Ass
y
220-2040 X X
232C PWB Ass
y
937J8SA1 X
937J9SA1 X
937J9SA4 X
937F0SA3 937F0SA2 X
CTL PWB Ass
y
937J8SB1 X
937J9SB3 937J9SB1 X
937J9SB4 X
937F0SB3 937F0SB2 X
LED PWB Ass
y
937J8SD1 X
937J9SD3 937J9SD1 X
937J9SD4 X
937F0SD3 937F0SD2 X
Control IR & LED Ass
y
220-2060 X X
Main AC switch Ass
y
937J8SC1 X
937J9SC2 937J9SC1 X
937J9SC4 X
937F0SC3 937F0SC2 X
Power Sw Ass
y
150-2040 X X
PROTECT PANEL ASSY
ADDRESS MODULES
11
