PDP-506PE
25
5678
56
7
8
C
D
F
A
B
E
3.4 50 SCAN A and B ASSYS
50 SCAN B ASSY
(UPPER)
50 SCAN A ASSY
(LOWER)
SA1
CN2802
CN2702
SB1
IC2801
Scan IC
IC2701
Scan IC
IC2702
Scan IC
IC2703
Scan IC
IC2704
Scan IC
IC2705
Scan IC
IC2706
Scan IC
IC2802
Scan IC
IC2803
Scan IC
IC2804
Scan IC
IC2805
Scan IC
IC2806
Scan IC
Serial Data
PSUS
Scan Signal
VH
IC5V
PSUS
Scan Signal
VH
IC5V
