PDP-503CMX, PDP-503MXE, PDA-5002
12
1 DIGITAL VIDEO Assy AWV1903
2 MX AUDIO Assy AWZ6644
3 X DRIVE Assy AWV1901
4 X CONNECTOR (A) Assy AWZ6618
5 X CONNECTOR (B) Assy AWZ6619
6 Insulation Sheet AMR3263
7 Flat Clamp AEC1879
NSP 8 Metal Fittings ANG2464
NSP 9 Heat Sink ANH1594
10 Coil Silicone Sheet AEH1048
11 Circuit Board Spacer AEC1872
12 Screw ABZ30P060FMC
13 Screw VBB30P100FNI
14 Screw PMB30P060FNI
15 J201 Flexible Flat Cable ADD1183
UNDER LAYER SECTION (3) PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
16 J202 Flexible Flat Cable ADD1183
17 J209 Flexible Flat Cable ADD1191
18 J204 Flexible Flat Cable ADD1196
19 J210 Flexible Flat Cable ADD1190
20 J211 Flexible Flat Cable ADD1186
21 J212 Flexible Flat Cable ADD1188
NSP 22 Holder ANG2498
23
24 Circuit Board Spacer AEC1872
25 V MID CLAMP Assy AWV1934
26 Niplocker BEC1136
