Pioneer PDP-503PE

PDP-503PE, PDP-503PU
22
2.9 UPPER LAYER SECTION (1)
S4001
CBIT_1
S4004
CBIT_0
PDP-503P → →
PDP-503PE ← →
PDP-503PU → →
Set the slide switches in accordance with applicable
model when replacing the MR INTERFACE Assy.
Note 1 : When there is not S4004, set only S4001.
Note 2 : When there are not S4001 and S4004, setting
is unnecessary.
Caution in the MR INTERFACE Assy Replacement
4
5
2
2
6
3
3
2
2
3
3
112
9
10
J5002 15
S4001
(CBIT_1)
S4004
(CBIT_0)
16
14
7
813
J201
J202
