Pioneer PDP-5040HD User Manual

06Part Names
English
13
En
Plasma Display
1 POWER button
2 STANDBY indicator
3 POWER ON indicator
4 Remote control sensor
1
2
4
3
5
6
7
8
(right view)
5 STANDBY/ON button
6 INPUT button
7 VOLUME +/– buttons
8 CHANNEL +/– buttons
0
9
-
=
Rear view
Front view
9 SYSTEM CABLE terminal (BLACK)
0 SYSTEM CABLE terminal (WHITE)
- SPEAKER (right/left) terminals
= AC INLET terminal
The terminals have faced downward.
