36
S-RS3SW
1
2 3 4
A
B
C
D
E
F
1
2 3 4
C 531 (B,80,17) CKSRYB223K50
C 532 (A,104,22) CEAT470M25
C 533 (B,89,19) CKSRYB392K50
C 534 (A,93,8) CEAL100M50
C 546 (A,93,41) ELECTR. CAPACITOR CEAL100M35
>
C 601 (A,194,18) CKA (10000P/AC250 V) ACG7034
C
REGULATOR ASSY
MISCELLANEOUS
>
Q 3 (A,167,97) TRANSISTOR 2SD2012
>
Q 4 (A,135,97) TRANSISTOR 2SB1375
Q 803 (B,173,74) TRANSISTOR RT1N241M
Q 804 (B,165,65) TRANSISTOR 2SC4081
Q 805 (B,168,79) TRANSISTOR 2SC4081
Q 806 (B,161,62) TRANSISTOR RT1N241C-12
D 9 (B,175,84) DIODE UDZS6R2(B)
D 10 (B,177,89) DIODE UDZS6R2(B)
D 11 (B,139,88) DIODE UDZS6R2(B)
D 12 (B,139,91) DIODE UDZS6R2(B)
D 801 (B,148,69) DIODE 1SS355
J 9 JUMPER WIRE D20PYY0510E
J 801 JUMPER WIRE D20PYY0310E
3 PCB BINDER VEF1040
9 (A,149,62) 5P CABLE HOLDER 51048-0500
801 (A,175,56) 3P CABLE HOLDER 51048-0300
CN 803 5P JUMPER CONNECTOR 51048-0300
RESISTORS
R 7 (B,172,91) RS1/16S1R0J
R 11 (B,133,94) RS1/16S100J
R 12 (B,140,94) RS1/16S1R0J
R 14 (B,167,88) RS1/16S100J
R 15 (A,160,69) METAL OXIDE RESISTOR RS3LMF122J
R 16 (A,160,75) METAL OXIDE RESISTOR RS3LMF122J
R 17 (A,168,91) METAL OXIDE RESISTOR RS1LMF123J
R 19 (A,129,81) METAL OXIDE RESISTOR RS1LMF123J
R 20 (A,134,75) METAL OXIDE RESISTOR RS3LMF122J
R 21 (A,134,69) METAL OXIDE RESISTOR RS3LMF122J
R 801 (B,146,66) RS1/16S682J
R 803 (B,138,67) RS1/16S472J
R 805 (B,173,77) RS1/16S223J
R 806 (B,166,84) RS1/16S103J
R 808 (B,173,64) RS1/16S683J
R 809 (B,164,75) RS1/16S103J
R 810 (B,164,69) RS1/16S103J
CAPACITORS
C 10 (A,163,91) ELECT. CAPACITOR CEAT470M35
C 17 (A,144,92) ELECT. CAPACITOR CEAT470M35
C 802 (A,169,64) CEAT100M50
D
TRANS ASSY
MISCELLANEOUS
H 1 (A,17,59) FUSE CLIP AKR7001
H 2 (A,17,39) FUSE CLIP AKR7001
J 4 CABLE ASSY XDX3080
>
CN 1 (A,18,31) CONNECTOR B2P3-VH
>
CN 3 (A,23,69) CONNECTOR B2P3-VH
Mark No. Description Part No.
CAPACITORS
>
C 13 (A,25,49) FILM CAPACITOR ACE7022
E
LED ASSY
MISCELLANEOUS
D 702 (A,23,115) LED(GREEN) SLI-343M8C(FGHJ)
CN 701 (A,23,133) 3PJUMPER CONNECTOR 52151-0310
F
FAN ASSY
MISCELLANEOUS
CN 901 (A,239,18) 3P TOP POST B3B-EH
CN 902 (A,239,35) 3P JUMPER CONNECTOR 52147-0310
4 PCB BINDER VEF1040
Mark No. Description Part No.
