Pioneer SC-LX701 User Manual

12
> Specifications > Settings > Listening Modes > Playback Function > Basic Manual
Troubleshooting | Appendix
Setting Item Default Value Setting Details
Height 2 Speaker Rear High Set the speaker type if height speakers are
connected to the HEIGHT 2 terminals. Select
"Front High", "Top Front", "Top Middle", "Top
Rear", "Rear High", "Dolby Speaker (Front)",
"Dolby Speaker (Surr)", or "Dolby Speaker (Back)"
according to the type and layout of the connected
speakers. However, the options selectable for the
"Height 1 Speaker" the are as follows.
If "Height 1 Speaker" is set to "Front High": Select
from "Top Middle", "Top Rear", "Rear High", "Dolby
Speaker (Surr)", or "Dolby Speaker (Back)".
If "Height 1 Speaker" is set to "Top Front" or "Dolby
Speaker (Front)": Select from "Top Rear", "Rear
High", "Dolby Speaker (Surr)", or "Dolby Speaker
(Back)".
If "Height 1 Speaker" is set to "Top Middle": Fixed
to "Rear High".
•
"Dolby Speaker (Surr)" and "Dolby Speaker
(Back)" can only be selected when surround
speakers or surround back speakers are being
used, respectively. You can check speakers that
you are using on the figure displayed in "System
Setup" - "Speaker" - "Configuration" - "Speaker
Channels".
•
If an item cannot be selected even though
connection is correct, check that the settings in
"System Setup" - "Speaker" - "Configuration"
- "Speaker Channels" matches the number of
connected channels.
Setting Item Default Value Setting Details
Zone Speaker No Set the connection of speakers to Zone 2 or Zone
3 speaker terminals.
"Zone 2": When speakers are connected only to
Zone 2 speaker terminals
"Zone 2/Zone 3": When speakers are connected to
both Zone 2 and Zone 3 speaker terminals
•
"Zone 2/Zone 3" cannot be selected when
surround back speakers and height speakers
are being used.
"No": When speakers are not connected to either
speaker terminals
•
This item will be set to "No" when two sets of
height speakers are being used.
Speaker B No Set whether you will use the Speaker B system.
"No": Speaker B system will not be used
"Yes": Speaker B system will be used without bi-
amp connection
"Bi-Amp": Speaker B system will be used with bi-
amp connection
•
"Bi-Amp" cannot be selected when height
speakers are being used.
•
In any of the following cases, this item will be
set to "No":
–
When "System Setup" - "Speaker" -
"Configuration" - "Zone Speaker" is set to
other than "No"
–
When two sets of height speakers are being
used

Pioneer SC-LX701 Specifications

General

Display	-
Product color	Silver
Audio decoders	DTS 96/24, DTS-ES, DTS-HD, DTS-HD HR, DTS-HD Master Audio, Dolby Digital Plus, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Apple docking compatibility	Not supported
Receiver type	Surround
Frequency range	20 - 20000 Hz
Audio output channels	9.2 channels
Dynamic power per channel (4 Ohm)	220 W
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
Digital audio optical in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	3.5 mm
Multichannel audio output type	Terminals
Speakers connectivity type	Binding post
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Supported radio bands	AM, FM
Preset stations quantity	40
Internet radio services supported	Pandora, TuneIn
Card reader integrated	No
AC input voltage	220-230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	310 W
Supported video modes	1080p, 2160p
Cables included	AC

Weight and Dimensions

Depth	441 mm
Width	435 mm
Height	185 mm
Weight	15300 g
