• This product (×1)
• Power cord (×1)
• Pre out cord (×1)
• USB cable (×1)
• LCD screen mounting bracket (×1)
• Spacer (×1)
• Flush surface screw (5 mm × 8 mm, Silver)
(×6)
• Binding head screw (5 mm × 8 mm,
Silver) (×6)
• Binding head screw with adhesive (4 mm
× 30 mm, Silver) (×4)
• Binding head screw with adhesive (4 mm
× 12 mm, Silver) (×4)
• Machine screw (2 mm × 4 mm, Black) (×4)
• GPS aerial (×1)
• Metal sheet (×1)
• Double-sided tape (×1)
• Clamps (×3)
• Microphone (×1)
• Double-sided tape (×1)
• Manual(s) (×1)
• Warranty Card (×1)
• D
o not operate this product, any
applications, or the rear view camera
option (if purchased) if doing so will
divert your attention in any way from the
safe operation of your vehicle. Always
observe safe driving rules and follow all
existing traffic regulations. If you
Checking supplied items
This product/
connection cables/
installation parts
Screws (nominal
diameter × length,
colour)
GPS aerial/installation
parts
Microphone/
installation parts
Other items
Connection
Precautions
Your new product and this
manual
experience difficulty in operating this
product, pull over, park your vehicle in a
safe location and apply the handbrake
before making the necessary
adjustments.
• Do not install this product where it may
(i) obstruct the driver’s vision,
(ii) impair the performance of any of the
vehicle’s operating systems of safety
features, including airbags, hazard lamp
buttons, or
(iii) impair the driver’s ability to safely
operate the vehicle.
In some cases, it may not be possible to
install this product beca
use of the vehicle
type or the shape of the vehicle interior.
Pioneer does not recommend that you
install this product yourself. This product is
designed for professional installation only.
We recommend that only authorised
Pioneer service personnel, who have
special training and experience in mobile
electronics, set up and install this product.
NEVER SERVICE THIS PRODUCT YOURSELF.
Installing or servicing this product and its
connecting cables may expose you to the
risk of electric shock or other hazards, and
can cause damage to this product that is
not covered by warranty.
• Secure all wiring with cable clamps or
electrical tape. Do not allow any bare
wiring to remain exposed.
• Do not directly connect the yellow lead of
this product to the vehicle battery. If the
lead is directly connected to the battery,
engine vibration may eventually cause
the insulation to fail at the point where
the wire passes from the passenger
compartment into the engine
compartment. If the yellow lead’s
insulation tears as a result of contact with
metal parts, short-circuiting can occur,
resulting in considerable danger.
• It is extremely dangerous to allow cables
to become woun
d around the steering
column or gearstick. Be sure to install this
product, its cables, and wiring away in
such so that they will not obstruct or
hinder driving.
• Make sure that the cables and wires will
not interfere with or become caught in
any of the vehicle’s moving parts,
especially the steering wheel, gearstick,
handbrake, sliding seat tracks, doors, or
any of the vehicle’s controls.
• Do not route wires where they will be
exposed to high temperatures. If the
insulation heats up, wires m
ay become
damaged, resulting in a short circuit or
malfunction and permanent damage to
the product.
• Do not shorten any leads. If you do, the
protection circuit (fuse holder, fuse
resistor or filter, etc.) may fail to work
properly.
• Never feed power to other electronic
products by cutting the insulation of the
power supply lead of this product and
tapping into the lead. The current
capacity of the lead will be exceeded,
causing overheating.
• Use this unit with a 12-volt battery and
negative earthing only. Fail
ure to do so
may result in a fire or malfunction.
