VSA-E08
2
1. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k RN1/4PC F562 x 10
1
5621
CONTRAST TABLE
Part No.
Ref. No. Mark Symbol and Description VSX-39TX VSA-E08 VSA-E08 Remarks
/KU/CA /HY /HV
PCB ASSEMBLIES
NSP MAIN ASSY AWK7640 AWK7644 AWK7644
P5- 5 MAIN CONTROL ASSY AWX7705 AWX7709 AWX7709
P5-12 VIDEO ASSY AWX7307 AWX7676 AWX7676
NSP COMPLEX ASSY AWK7497 AWK7509 AWK7556
P5- 2 EXTERNAL IN (EXTRA-5.1) ASSY AWX7314 AWX7348 AWX7348
P5- 3 A-PINJACK ASSY AWX7312 AWX7346 AWX7346
P5- 4 CONNECTION ASSY AWX7313 AWX7558 AWX7558
P5- 9 REGULATOR ASSY AWX7310 AWX7559 AWX7559
P5-11 TRANS 2-2 ASSY AWX7366 AWX7470 AWX7470
P5-15 PRIMARY ASSY AWX7311 AWX7345 AWX7454
NSP FRONT/VAMP ASSY AWK7667 AWK7659 AWK7659
P5-19 V-AMP ASSY AWX7729 AWX7730 AWX7730
P9- 2 DISPLAY ASSY AWX7698 AWX7701 AWX7701
P- SW ASSY Not used AWX7330 AWX7330 No. 1
NSP POWER/CURRENT ASSY AWK7650 AWK7634 AWK7634
P5- 8 SP / PS ASSY AWX7658 AWX7690 AWX7690
PACKING SECTION
P3- 1 AM Loop Antenna ATB7009 Not used Not used
P3- 2 FM Wire Antenna ADH7007 Not used Not used
P3- 3 Operating Instructions (English) ARB7230 ARB7233 ARB7233
P3- 3 Operating Instructions (German) Not used ARC7307 Not used
P3- 3 Operating Instructions (French) Not used ARC7308 Not used
P3- 3 Operating Instructions (Italian) Not used ARC7309 Not used
P3- 3 Operating Instructions (Dutch) Not used ARC7310 Not used
P3- 3 Operating Instructions (Swedish) Not used ARC7311 Not used
P3- 3 Operating Instructions (Spanish) Not used ARC7312 Not used
P3- 4 Remote Control Unit (39) AXD7254 Not used Not used
P3- 4 Remote Control Unit (E08) Not used AXD7255 AXD7255
* 1
P3- 7 Front Pad AHA7255 AHA7253 AHA7253
P3- 8 Rear Pad AHA7256 AHA7254 AHA7254
P3- 9 Packing Case AHD7882 AHD7886 AHD7886
P3-12 NSP Warranty Card ARY1026 ARY7022 ARY7022
P3-13 Spacer 29 AHB7033 Not used Not used
P3-13 Spacer 26 Not used AHB7032 AHB7032
VSA-E08/HY, HV and VSX-39TX/KU/CA are constructed the same except for the following :
*1 : Refer to “4. REMOTE CONTROL UNIT”.
To Next Page
