Piper PA-44-180T TURBO SEMINOLE User Manual

Figure 30-11. Typical Deicer Boot Sealer Application
Figure 30-12. Wrinkled Deicer
C180
SHADED AREA
REPRESENTS
SEALER
SECTION B - B
SECTION A - A
DEICER
DEICER
CEMENTED AREA
CEMENTED AREA
FILLER
SEALER
SEALER
DEICER
DISTANCE OF FILLER
APPLICATION (BOTH
SIDES OF DEICER)
B
B
A
A
21/2”
1/8
1/8
1/8
1/8
1/2
1/4
1/2
1/4
400
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
3 0 - 6 8 - 0 8
Page 30-42
Revised: May 15, 1989
2E22
PIPER AIRCRAFT

Piper PA-44-180T TURBO SEMINOLE Specifications

General

Horsepower	180 hp (each engine)
Length	27 ft 7 in (8.41 m)
Height	8 ft 6 in (2.59 m)
Seating Capacity	4
Service Ceiling	20, 000 ft (6, 096 m)
Maximum Takeoff Weight	3, 800 lbs
Aircraft Type	Light Twin-Engine Piston Aircraft
