Figure 6-1. Three View
PIPER AIRCRAFT
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
6-10-00
Page 6 - 04
Revised: June 20, 1995
1B19
(3, 05m)
1 0 '
(2, 54m)
8' 3.96"
(2, 17m)
7' 1.56"
(0, 64 m)
2' 1.20"
(3, 84 m)
12' 7.14"
(3, 21 m)
10' 6.5"
(2, 59 m)
8' 6.00"
2, 56 m)
8' 4.80"
(11, 75 m) 38' 6.6"
(8, 41 m) 27' 7.20"

Piper PA-44-180T TURBO SEMINOLE Specifications

General

Horsepower	180 hp (each engine)
Length	27 ft 7 in (8.41 m)
Height	8 ft 6 in (2.59 m)
Seating Capacity	4
Service Ceiling	20, 000 ft (6, 096 m)
Maximum Takeoff Weight	3, 800 lbs
Aircraft Type	Light Twin-Engine Piston Aircraft
