Figure 81-1. Schematic Diagram of Typical Turbocharger System
2043
COMPRESSOR HOUSING
COMPRESSOR WHEEL
AIR INLET
COMPRESSOR
AIR DISCHARGE
ABSOLUTE
PRESSURE RELIEF
VALVE
THROTTLE
AMBIENT AIR
EXHAUST INLET
EXHAUST TURBINE HOUSING
TURBINE WHEEL
TAIL PIPE
EXHAUST DISCHARGE
GROUND ADJUSTABLE
EXHAUST BYPASS VALVE
TURBOCHARGED AIR
EXHAUST AIR
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
8 1 - 2 2 - 0 0
Page 81-08
Revised: May 15, 1989
3J10
PIPER AIRCRAFT

Piper PA-44-180T TURBO SEMINOLE Specifications

General

Horsepower	180 hp (each engine)
Length	27 ft 7 in (8.41 m)
Height	8 ft 6 in (2.59 m)
Seating Capacity	4
Service Ceiling	20, 000 ft (6, 096 m)
Maximum Takeoff Weight	3, 800 lbs
Aircraft Type	Light Twin-Engine Piston Aircraft
