Part# Description
1 Chimney Cap (x1)
2 Chimney Stack (x1)
3 Main Cabinet (x1)
4 Fixed Support (x1)
5 Cabinet Door Latch (x1)
6 Cabinet Door Handle (x1)
7 Grease Exhaust Tube (x1)
8 Cooking Grid (x3)
9 Cooking Grid Support Brackets (x6)
1/4”-20 x 3/5” Screw (x4)
1/4” Washer (x4)
1/4” Locking Washer (x4)
1/4”-20 x 9/5” Screw (x2)
5/32” - 32 x 2/5” Screw (x18)
NOTE: Due to ongoing product development, parts are subject to change without
notice. Contact Customer Service if parts are missing when assembling the unit.
Parts are located throughout the shipping carton, including underneath the smoker. Inspect the smoker, parts, and hardware
blister pack after removing from the protective shipping carton. Discard all packaging materials from inside and outside of the
grill before assembly, then review and inspect all parts by referencing the parts list. If any part is missing or damaged, do not
attempt to assemble. Shipping damage is not covered under warranty. Contact your dealer or Pit Boss® Customer Service for
parts: Monday through Sunday, 4am - 8pm PST (EN/FR/ES).
service@pitboss-grills.com | Toll-Free: 1-877-303-3134 | Toll-Free Fax: 1-877-303-3135
IMPORTANT: To ease installation, using two people is helpful (but not necessary) when assembling this unit.
Tools required for assembly: screwdriver, wrench and level.
Tools not included.
2
54
3
6
7
8
9
1
MODEL UNIT ASSEMBLED (WxHxD)
UNIT WEIGHT
COOKING AREA TEMPERATURE RANGE
0600
442 mm x 487 mm x 670 mm
/ 17.4” x 19.17” x 26.37”
18 kg
/ 39.68 lb
Main
- 1,599.7 cm / 247.95 sq. in.
Additional Racks
- 2,979.6 cm / 461.84 sq. in.
TOTAL
- 4,579.3 cm / 709.79 sq. in.
38-232°C
/ 100-450°F
