11042

..

P B10 2 0 N X 26,000 BTU

CHARLESTONCHARLESTON

*    

.     

   . 

    

 .

300522

READ ALL INSTRUCTIONS

BEFORE INSTALLING AND

USING THE APPLIANCE,

SAVE THESE INSTRUCTIONS.

LISEZ TOUTES LES INSTRUCTIONS

AVANT D'INSTALLER ET

D'UTILISER L'APPAREIL,

CONSERVEZ CES INSTRUCTIONS.

LEA TODAS LAS INSTRUCCIONES

ANTES DE INSTALAR Y

UTILIZAR EL APARATO, GUARDE

ESTAS INSTRUCCIONES.

Table of Contents

Questions and Answers:

A
Angela HernandezAug 19, 2025
What to do if my Pit Boss PB1020NX Grill shows an "ErH" error code?
- T
  Tina HillAug 20, 2025
  If the Pit Boss Grill displays the "ErH" error code, it indicates that the unit has overheated, possibly due to a grease fire or excess fuel. To resolve this, press and hold the Power Button for three seconds to turn the unit off and allow the grill to cool. After it cools, remove pellets and confirm the positioning of all component parts. Once cooled, press the Power Button to turn the unit on, then select the desired temperature. If the error code is still displayed, contact Customer Care.
P
Patricia CallahanAug 21, 2025
Why won't the burner light on my Pit Boss PB1020NX Grill?
- C
  Casey HallAug 22, 2025
  If your Pit Boss Grill burner will not light, first, visually confirm that the igniter is working by pushing the igniter button and looking at the igniter tip for a spark. Also, check the gas cylinder and hosing for issues, and inspect the regulator valve. Ensure sufficient airflow by adjusting the damper vents. Finally, visually confirm that the burner tube and portholes are not obstructed.
T
Tim GonzalesAug 25, 2025
What does the "ErL" error code mean on my Pit Boss PB1020NX?
- M
  Michael SmithAug 25, 2025
  If your Pit Boss Grill displays the "ErL" error code, it indicates that the grill fails to perform the start-up cycle. Check the proper positioning of cooking components and ensure the hopper has sufficient fuel and that there is no obstruction in the feed system. Also, try disconnecting the meat probe from the connection port on the Control Board, and then reconnect it, ensuring the meat probe adapter is firmly connected. Another possible cause is that the grill will not stay lit.
W
wilsonjessicaAug 26, 2025
What does it mean when the "Err" error code and Auger icon are blinking on my Pit Boss PB1020NX?
- C
  Cindy ScottAug 26, 2025
  If your Pit Boss Grill displays the "Err" error code and the Auger icon is blinking, it indicates that the auger motor is jammed or not making a connection. To resolve this, remove the cooking components from the main barrel, turn the unit on, and inspect the auger feed system. Visually confirm that the auger is dropping pellets into the burn pot.
B
bryceperezAug 27, 2025
What does it mean when the "Err" error code and Igniter icon are blinking on my Pit Boss PB1020NX?
- P
  Patricia MooneyAug 27, 2025
  If your Pit Boss Grill displays the "Err" error code and the Igniter icon is blinking, it means the igniter is not working properly or not making a connection. Remove the cooking components from the main barrel, turn the unit on, and inspect the igniter. Visually confirm that the igniter is working by placing your hand above the burn pot and feeling for heat.
S
scottcarlAug 29, 2025
What does it mean when the "Err" error code and Fan icon are blinking on my Pit Boss Grill?
- D
  David KingAug 29, 2025
  If your Pit Boss Grill displays the "Err" error code and the Fan icon is blinking, it indicates that the fan is not working properly or not making a connection. Check the fan to ensure it is working properly and that the air intake is not blocked.
S
sgreenSep 1, 2025
What does it mean when the "Err" error code and Pellet icon are blinking on my Pit Boss PB1020NX Grill?
- A
  antonio65Sep 1, 2025
  If the Pit Boss Grill displays the "Err" error code and the Pellet icon is blinking, it indicates a lack of fuel or poor fuel quality. Check the hopper to ensure that the fuel level is sufficient and replenish if low.
J
jenniferjohnsonSep 2, 2025
What does the "ErP" error code on my Pit Boss PB1020NX Grill mean?
- A
  Ashley RamirezSep 2, 2025
  If your Pit Boss Grill displays the "ErP" error code, it indicates that the grill probe wire is not making a connection. Remove the access panel and check for any damage to the Grill Probe wires. Disconnect and reconnect the Grill Probe connectors to the Control Board.
A
Alyssa BellSep 4, 2025
What does the "NoP" error code mean on my Pit Boss PB1020NX?
- J
  Jason BowmanSep 4, 2025
  If your Pit Boss Grill displays the "NoP" error code, it indicates a bad connection at the connection port. Check for signs of damage to the wires of the meat probe. If damaged, call Customer Care for a replacement part.
B
bryan43Sep 6, 2025
Why is my Pit Boss Grill producing excess or discolored smoke?
- B
  bellkennethSep 6, 2025
  If your Pit Boss Grill is producing excess or discolored smoke, it could be due to a dirty grill probe. Check the status of the Grill Probe and follow the Care and Maintenance instructions if it's dirty. Other possible causes are grease build-up (follow Care and Maintenance instructions), poor hardwood pellet quality (replace with dry pellets and clean out the moist pellets), a blocked burn pot (clear the burn pot), or insufficient air intake for the fan (ensure the fan is clean, working properly, and the air intake is not blocked).

Pit Boss PB1020NX Specifications

General

Brand	Pit Boss
Model	PB1020NX
Category	Grill
Language	English

Summary

IMPORTANT SAFEGUARDS

Propane Gas Safety Warnings

Safety precautions and regulations for using propane gas.

DANGERS AND WARNINGS

Clearance and Placement Requirements

Minimum clearance from combustible constructions to the grill.

Grease Fire Incident Protocol

Instructions for handling a grease fire incident.

Electrical Cord Safety

Safety guidelines for electrical cords and power supply.

ELECTRICAL WARNINGS

Approved Pellet Fuel

CARBON MONOXIDE HAZARDS

WOOD PELLET GRILL OPERATION

CONTROL BOARD FUNCTIONS

Power Button and Status

"P" Set Button for Auger Control

Controls auger feeding cycle rate.

Controller Knob Operation

Adjusts temperature and confirms values.

Prime Button for Quick Recovery

Meat Probe Connection Ports

SETTING UP THE GRILL

Outdoor Placement and Clearance

Instructions for positioning the grill outdoors safely.

WOOD PELLET GRILL OPERATION - TEMPERATURE

Setting The Temperature

Procedure for adjusting the grill's target temperature.

Using A Meat Probe

WOOD PELLET GRILL OPERATION - PRIMING & FIRST USE

Auger Priming Procedure

Steps to prime the auger for pellet feeding.

First Use Burn Off

Procedure for initial grill burn-off before first cooking.

WOOD PELLET GRILL OPERATION - REGULAR USE

Regular Use Instructions

Instructions for normal operation and startup.

COOKING & HOT SMOKING GUIDE

SMOKING AT LOW TEMPERATURES

SHUT-DOWN PROCEDURE

CONNECTING TO A GAS SUPPLY

Gas Cylinder Requirements

Specifications and requirements for LP gas cylinders.

Installing A Gas Cylinder

Step-by-step guide to connecting a gas cylinder.

GAS SUPPLY CONNECTIONS

Leak Testing Procedure

Procedure to check for gas leaks in the system.

Disconnecting A Gas Cylinder

Steps to safely disconnect the gas cylinder.

GAS GRIDDLE OPERATION

First Use Griddle Cleaning

Griddle Lighting Procedure

Steps for lighting the griddle burners.

GAS GRIDDLE OPERATION - MANUAL LIGHTING

Manual Lighting Procedure

Alternative method for lighting burners if igniter fails.

CARE & MAINTENANCE

Grill Interior Cleaning

CARE & MAINTENANCE - COMPONENTS

Burner Component Cleaning

Cleaning and inspection of burner parts and flame.

Hopper Assembly Cleaning

CARE & MAINTENANCE - PROBES & CHEAT SHEET

TROUBLESHOOTING - PELLET GRILL

Wood Pellet Grill Issues

Common issues and solutions for pellet grills.

TROUBLESHOOTING - ERRORS & FAULTS

Error Code Troubleshooting

Troubleshooting common error codes and their causes.

TROUBLESHOOTING - GAS GRIDDLE

Gas Griddle Problems

Common issues and solutions for gas griddles.
