¦ Rotate the reset knob in a counter-clockwise direction to completely
zero-out the partial indicator.
The total indicator cannot be reset to zero.
¦ Extract the dispensing nozzle (a) and insert it in the container to be
filled.
¦ Set the starting handle to position ON (b): the pump starts.
¦ Press the nozzle lever and keep it pressed until you have dispensed the
desired quantity.
¦ When dispensing is finished, set the start handle to OFF (c): the pump
stops. Replace the nozzle (d).
¦ Rehang the hose on the hose support hook, so that it will not be
crushed by moving vehicles.
INSTRUCTIONS FOR USE.
Transfer of fuel must always occur in the presence and under the control of the operator.
Keep the dispensing nozzle closed until it is inserted in the container to be filled.
If the nozzle lever is not completely pressed, the automatic release device will not work.
ATTENTION
How to
dispense fuel
Reset knob
Hose
support
hook
a c
b d
