CUBE • MC
10 TECHNICAL SPECIFICATIONS
10.1 TECHNICAL DATA
MODEL Voltage Frequency Power Absorption Max Flow Rate
CUBE MC70 MC 230 V 50 HZ 900 W 4,2 A 70 l/min
CUBE MC70 MC 110 V 60 HZ 550 W 5,5 A 69 l/min
10.2 POWER CONSUPTION
NOTE
The CUBE MC stations must be powered by a power line with the same RAT-
ED VOLTAGE /FREQUENCY as that indicated on the identification plate.
The following max. variations can be accepted:
- VOLTAGE +/- 5%
- FREQUENCY +/- 2%
ATTENTION
Power supply from lines with values that do not fall within the indicated
limits could cause damage to the electrical components.
The IDENTIFICATION PLATE shows maximum ABSORBED POWER (in Am-
pères), with respect to which, the power protection appliances required by
applicable standards (not supplied with the station) must be sized. The maxi-
mum absorbed power refers to intended-use operation - DISPENSING OF
DIESEL FUEL - with power supply within the above-mentioned limits.
11 INTENDED USE
WARNING
Flammable
liquids and
explosive
atmosphere
The system was not designed for dispensing of diesel, petrol, flammable
liquids with flash point <55°C/131°F, or for operation in environments with
potentially explosive atmosphere. The use in the above mentioned condi-
tions is forbidden.
ATTENTION
Environmental
conditions
The use of the system for purposes different from those specified in section
«Intended use» is strictly forbidden. Do not operate the system for any
purpose other than the purpose described within this manual; all other use
is considered «IMPROPER» and will result in Piusi S.p.A. disclaiming any
responsibility for damage to property, people, animals or to the system
itself.
Fluid Permitted
DIESEL FUEL at a VISCOSITY from 2 to 5.35 cSt (at a temperature of 37.8°
/ 100°F C). Minimum Flash Point (PM): 55°C / 131°F (In accordance with the
EN590)
ATTENTION
Environmental
conditions
TEMPERATURE: min. –20° C / max +60° C
RELATIVE HUMIDITY: max. 90%
The temperature limits shown apply to the pump components and must be
respected to avoid possible damage or malfunction.
