Pixsys ATR 121 - Page 25

25
Absolute with
manual reset
(after alarm
activation, press
FNC key to reset
the output) ;
status of relay
stored in case of
switch-off
Normally open,
active at Start
(default)
Normally closed,
active at Start
Normally open,
active at alarm
setpoint
1
20
State of
contact for
alarm output
and type of
operating
Normally closed,
active at alarm
setpoint
1
Open contact
safety (default)
21
State of
contact for
alarm output
in case of
error
Closed contact
safety
ON with open
contact
22
ATR121
ATR141
State of led
OUT2
according to
relevant
contact
ON with closed
contact (default)
1
At starting the output is desabled in case of any alarm
condition. After the alarm has been solved, output will be
activated only if alarm condition should occur again.
