R1224 Regulator

Installation Instruction

24-30-01 12-1001

Page: 6-2 Rev. M: 01 Dec. 2021

Note: All twin engines must replace

both regulators

OEM Regulator P/N

Plane Power

Regulator P/N

Supplement

Information

Cessna Aircraft Company

182, 182A, 182B, 182C, 182D, 182E, 182F, 182G, 210,

210A, 210B, 210-5 (205), 185, 185A, 185B, 185C, 180,

180A, 180B, 180C, 180D, 180E, 180F, 180G, 206, P206

InterAv 625-61623 R1224 Guide M

152, A152, 172I, 172K, 172L, 172M, 172N, 172P, R172,

172RG, R172K, FR172, 177, 177A, 177B, 177RG, 180H,

180J, 180K, 182G, 182H, 182J, 182K, 182L, 182M, 182N,

182P, 182Q, 182R, R182, T182, TR182, 185D, 185E,

188, 188A, 188B, A188, A188A, A188B, T188C, P206A,

P206B, P206C, P206D, P206E, TP206A, TP206B, TP206C,

TP206D, TP206E, U206, U206A, U206B, U206C, U206D,

U206E, U206F, U206G, P206A, P206B, P206C, P206D,

P206E, TU206A, TU206B, TU206C, TU206D, TU206E,

TU206F, TU206G, 207, T207, 210B, 210C, 210D, 210E,

210F, 210G, 210H, 210K, 210L, 210M, 210N, P210N,T210F,

T210G, T210H, T210J, T210K, T210L, T210M, 182Q, 182R,

T182, R182, TR182, 188, 188A, 188B, A188, A188A, A188B

Cessna 0750216-1, 611001-

0101, C611001-0102,

C611001-0201

R1224 Basic

(Two Wire) Cessna C611004,

611005-0101, C611005-0102,

C611005- 0103

R1224 Guide B

(Four Wire) Cessna C611501-

0102, 611504-0103 **

R1224 Guide C

C611002-0102, 611002-0105,

611004-0101, C611004-0102,

R1224 Guide L

337F, 337G, 337H, FT337P,

T337F, T337G, T337H, F337H,

F337G, P337H

R1224 Guide B

310R, T310R, 335, 340, 340A,

402C,404, 414, 421, 421A,

421B, 421C

R1224 Guide H

150, 170, 172, 175 WITH STC SA971WE installed J12M20SP, J12M24SP R1224J Guide N

Commander

114, 114A, 114B, 114TC Rockwell B-00331-1 R1224 Guide A

114B, 114TC

(4 Wire Regulators)

Electrodelta VR515G **

R1224 Guide C

Grumman

G-164A with STC SA2015WE installed J12M20SP, J12M24SP R1224J Guide N

Helio Aircraft LLC

H-250, 500 InterAv 625-61623 R1224 Guide M

Interceptor

200, 200A, 200B, 200C, 200D InterAv 625-61623 R1224 Guide M

KAWAD Company

Super-V Interav 625-61623 R1224 Guide M

Lockheed Aircraft

402-2 InterAv 625-61623 R1224 Guide M

Lake

LA4-200, Serial 500 and on, Lake Model 250

Electrodelta VSF-7202, VSF-

7204

R1224 Guide G

LA-4, Colonial C1 & C2 InterAv 625-61623 R1224 Guide M

** Requires purchase of adapter plate P/N: 12-1021

Table 6-1 - Effectivity (cont.)
