Page 8
LED Indicators
LEDs - FPS-5P-S, FPS-5P-M
FPS-5P-S and FPS-5P-M have two LED indicators on the top. The Status/Error LED
is orange or red. The Power/Link indicator LED is green. The LED indicator modes are
described in the following table.
Green LED Red/Orange LED Status Description
Off Off No power.
On On Hardware error.
Flashing Flashing Firmware upgrade in progress.
On Off Normal operation - idle.
Flashing Off Normal operation - transmitting or
receiving packets from the network.
LEDs - FPS-2PUW
FPS-2PUW has 4 additional LED indicators as follows:
LED Description
LAN Off - Idle
Flashing - Transmitting or receiving data through the LAN.
WLAN Off - Idle
Flashing - Transmitting or receiving data through the Wire-
less LAN.
ACT Off - Printserver is not power on
Flashing - Printserver is working
ERR Off – Printer is working fine
On - For FPS-2PUW. The printserver is resetting.
LEDs - FPS-1UA
FPS-1UA has 2 additional LED indicators as follows:
LED Description
PWR Off - Printserver is not power on
Flashing - Printserver is working
USB Off – Printer is working fine
Flashing - No printer connected to the USB port
