SNMP
The Print Server supports SNMP (Simple Network Management Protocol). This allows
network supervisors to monitor and control the Print Server using network manage-
ment platforms such as HP OpenView, IBM SystemView, etc.
The appropriate MIB file must be imported into your SNMP management program us-
ing the Import-Compile command. Check your management program for details on
this procedure. The MIB files are provided in the MIB folder on the CD-ROM, as fol-
lows:
Mib1p.mib Single port models.
Mib3p.mib Models with 3 parallel ports
FPS-1UA, FPS-2PUW and FPS-2PUWG are not support SNMP protocol. So you can
not find the MIB file for them.
Configuring the Print Server for SNMP
Before using a SNMP Management station to manage the Print Server, the following
settings should be assigned to it, in addition to the IP Address, Gateway Address, and
Subnet Mask.
SNMP Settings
SysContact
Text Field - Name of the contact person.
SysLocation
Text Field - Location of the contact person.
Management Station
IP Address(s)
Up to 4 Management Stations can be entered.
Trap Receiving
IP Address(s)
Up to 4 Trap Receiving Stations can be entered.
Management Station Settings
For each Management Station, the following fields are available:
Access Permission
Options are:
Read Only
Read/Write
Not Accessible
Community String
Leaving this blank will disable management by this sta-
tion.
Trap Receiving Station Settings
For each Trap Receiving Station, the following fields are available:
Community String
Leaving this blank will disable management by this sta-
tion.
Trap Enable
Use this option to Enable/Disable Trap Receiving by this
station.
Trap Severity
In this version, all traps are level 1.
