11
Power Requirements
AC 100~240V,
50/60Hz,
2.5A max.
100~240V AC, 50/60Hz, 5A max.
Power Consumption/
Dissipation
Max. 130
watts/446 BTU
Max. 330 watts/1132 BTU
Thermal Fan 1 2
Power over Ethernet
PoE Standard
IEEE 802.3af Power over Ethernet/PSE
IEEE 802.3at Power over Ethernet Plus/PSE
PoE Power Supply Type End-span
PoE Power Output
Per port 53V-54V DC, 300mA. max. 15.4 watts
(IEEE 802.3af)
Per port 53V-54V DC, 600mA. max. 30 watts (IEEE
802.3at)
Power Pin Assignment 1/2 (+), 3/6 (-)
PoE Power Budget 120 watts 300 watts
Max. Number of Class 2 PDs 8 16 24
Max. Number of Class 3 PDs 8 16 23
Max. Number of Class 4 PDs 4 11 11
Standards Conformance
Regulatory Compliance FCC Part 15 Class A, CE
Standards Compliance
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab Gigabit 1000BASE-T
IEEE 802.3z Gigabit SX/LX
IEEE 802.3x Flow control and back pressure
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
Environment
Operating
Temperature: 0 ~ 50 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
Storage
Temperature: -10 ~ 70 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
