2. Hardware Description
These switches provide three different running speeds – 10Mbps, 100Mbps and
1000Mbps and automatically distinguish the speed of the incoming connection.
This section describes the hardware features of 802.3at PoE+ Switch. For easier
management and control of the 802.3at PoE+ Switch, familiarize yourself with its
display indicators and ports. Front panel illustrations in this chapter display the unit
LED indicators. Before connecting any network device to the 802.3at PoE+ Switch,
please read this chapter carefully.
2.1 Front Panel
The Front Panel of the 802.3at PoE+ Switch consists of 8/16/24 802.3af/802.3at
auto-sensing 10/100/1000Mbps Ethernet RJ45 ports and 2 Gigabit TP/SFP ports .
The LCD monitor and LED Indicators are also located on the front panel of the
802.3at PoE+ Switch.
4 6 82
1 3 5 7
10
9
1
PWR
Standard
VLAN
Extend
PoE Port Status
5
3 7
2 6
4 8
9
10
PoE
PoE
GSD-1002VHP
8-Port 10/100/1000T 802.3at PoE
+
2-Port 10/100/1000T Desktop Switch
PoE In-Use
ACTLNK1000
ACTLNK10/100
Figure 2-1: GSD-1002VHP Switch Front Panel
1
PWR
5 9 13
3 7 11 15
PoE
2 6 10 14
4 8 12 16
PoE
SFP
18
4 6 82
1 3 5 7
12 14 1610
9 11 13 15
PoE Port Status
GSW-1820VHP
PoE In-Use
ACTLNK1000
ACTLNK10/100
ACT
LNK
SFP
Standard
VLAN
Extend
17 18
17
16-Port 10/100/1000T
802.3at PoE
+
2-Port Gigabit
SFP Ethernet Switch
Figure 2-2: GSW-1820VHP Switch Front Panel
1
PWR
5 9 13 17 21
3 7 11 15 19 23
PoE
2 6 10 14 18 22
4 8 12 16 20 24
PoE
24-Port 10/100/1000T
802.3at PoE
+
2-Port Gigabit
SFP Ethernet Switch
SFP
4 6 82
12 14 1610
20 22 2418
PoE Port Status
GSW-2620VHP
PoE In-Use
ACTLNK1000
ACT
LNK
SFP
25 26
Standard
VLAN
Figure 2-3: GSW-2620VHP Switch Front Panel
Gigabit TP Interface
10/100/1000BASE-T copper, RJ45 twisted-pair: Up to 100 meters.
Gigabit SFP Slots
1000BASE-SX/LX mini-GBIC slot, SFP (Small Factor Pluggable) transceiver
module: From 550 meters (multi-mode ber) to 10/20/30/40/50/60/70/120 kilo-
meters (single-mode ber).
