 DIP Switch
The DIP switch that is located on the front panel of the GSD-1002VHP, GSW-
1820VHP, GSW-2620VHP 802.3at PoE+ Switch provides “Standard”, “VLAN”
and “Extend” mode selection; the “Extend” mode features 30-watt PoE
transmit distance of 250m at speed of 10Mbps.
Model GSD-1002VHP GSW-1820VHP GSW-2620VHP
DIP
Switch
Mode
Function
Standard
(default)
This mode makes the 802.3at PoE+ Switch operate as a general
switch and all PoE ports operate at 10/100/1000Mbps auto-negotiation.
VLAN
This mode makes the
GSD-1002VHP operate
as a VLAN isolation
switch and
1. Port 1 to port 8 will
isolate respectively.
2. Port 1 to port 8 can
only communicate
with port 9 and port
10 (uplink port).
This mode makes the
GSW-1820VHP operate
as a VLAN isolation
switch and
1. Port 1 to port 16/24
will isolate respec-
tively.
2. Port 1 to port 16
can only commu-
nicate with port 17
and port 18 (uplink
port).
This mode makes the
GSW-2620VHP operate
as a VLAN isolation
switch and
1. Port 1 to port 24
will isolate respec-
tively.
2. Port 1 to port 24
can only commu-
nicate with port 25
and port 26 (uplink
port).
Extend
With
VLAN
This mode makes the
GSD-1002VHP operate
as a VLAN isolation
switch and
1. Port 1 to port 8 will
isolate respectively.
2. Port 1 to port 8 can
only communicate
with port 9 and port
10 (uplink port).
3. 30-watt PoE trans-
mit distance of
250m at speed of
10Mbps.
This mode makes the
GSW-1820VHP operate
as a VLAN isolation
switch and
1. Port 1 to port 16
will isolate respec-
tively.
2. Port 1 to port 16
can only commu-
nicate with port 17
and port 18 (uplink
port).
3. 30-watt PoE trans-
mit distance of
250m at speed of
10Mbps.
This mode makes the
GSW-2620VHP operate
as a VLAN isolation
switch and
1. Port 1 to port 24
will isolate respec-
tively.
2. Port 1 to port 24
can only commu-
nicate with port 25
and port 26 (uplink
port).
3. 30-watt PoE trans-
mit distance of
250m at speed of
10Mbps.
Table 2-1: GSD/GSW 802.3at PoE+ Switch DIP Switch Description
