2.1.2 LED Indicators
System
LED Color Function
PWR Green Lights to indicate that the Switch has power.
Per 10/100/1000Mbps Port with PoE Interfaces
LED Color Function
LNK/ACT Orange
Lights:
Indicates the link through that port is success-
fully established at 10/100Mbps.
Blinks:
Indicates that the Switch is actively sending
or receiving data over that port.
LNK/ACT Green
Lights:
Indicates the link through that port is success-
fully established at 1000Mbps.
Blinks:
Indicates that the Switch is actively sending
or receiving data over that port.
PoE
In-Use
Orange
Lights:
Indicates the port is providing 53V DC in-line
power.
Off:
Indicates the connected device is not a PoE
Powered Device (PD).
Per 1000Mbps SFP Slot
LED Color Function
LNK/ACT Green Lights
Indicates that the Switch is actively sending
or receiving data over that port.
1000 Green Lights
Indicates the port is successfully established
at 1000Mbps.
