 Approved PLANET SFP Transceivers
PLANET 802.3at PoE+ Switch supports both single mode and multi-mode SFP
transceivers. The following list of approved PLANET SFP transceivers is correct at
the time of publication:
Gigabit SFP Transceiver Modules
 MGB-GT
SFP-Port 1000BASE-T Module
 MGB-SX
SFP-Port 1000BASE-SX mini-GBIC module - 550m
 MGB-LX
SFP-Port 1000BASE-LX mini-GBIC module - 10km
 MGB-L30
SFP-Port 1000BASE-LX mini-GBIC module - 30km
 MGB-L50
SFP-Port 1000BASE-LX mini-GBIC module - 50km
 MGB-L70
SFP-Port 1000BASE-LX mini-GBIC module - 70km
 MGB-L120
SFP-Port 1000BASE-LX mini-GBIC module - 120km
 MGB-LA10
SFP-Port 1000BASE-LX (WDM, TX:1310nm) - 10km
 MGB-LB10
SFP-Port 1000BASE-LX (WDM, TX:1550nm) - 10km
 MGB-LA20
SFP-Port 1000BASE-LX (WDM, TX:1310nm) - 20km
 MGB-LB20
SFP-Port 1000BASE-LX (WDM, TX:1550nm) - 20km
 MGB-LA40
SFP-Port 1000BASE-LX (WDM, TX:1310nm) - 40km
 MGB-LB40
SFP-Port 1000BASE-LX (WDM, TX:1550nm) - 40km
Note
It is recommended to use PLANET SFP on the 802.3at PoE+
Switch. If you insert an SFP transceiver that is not supported, the
802.3at PoE+ Switch will not recognize it.
1. Before we connect the 802.3at PoE+ Switch to the other network device, we
have to make sure both sides of the SFP transceivers are with the same media
type, for example, 1000BASE-SX to 1000BASE-SX; 1000BASE-LX to 1000BASE-
LX.
2. Check whether the ber-optic cable type matches with the SFP transceiver
requirement.
 To connect to 1000BASE-SX SFP transceiver, please use the multi-mode ber
cable with one side being the male duplex LC connector type.
 To connect to 1000BASE-LX SFP transceiver, please use the single-mode ber
cable with one side being the male duplex LC connector type.
