Please adjust the DIP switch before powering on the 802.3at
PoE+ Switch.
Standard Mode (default)
Power
100 meters (328 feet)
PoE
PoE
100BASE-T UTP with PoE
PoE IP Camera
GSW-2620HP
Standard
VLAN
Extend
PoE
100BASE-TX UTP with PoE
VLAN Isolation Mode
PC
Ports 1 to 22
Access Denied
PoE
PoE
PoE
1000BASE-T UTP
IP Camera
Ports 23~24 and Ports 25~26
to Ports 1~22 Access Permitted
NVR
GSW-2620HP
Standard
VLAN
Extend
IP Camera
IP Camera
Extend Mode
Ports 1 to 8
Power
250 meters (820 feet)
PoE
PoE
10BASE-T UTP with PoE
PoE IP Camera
GSW-2620HP
Standard
VLAN
Extend
