4.Web-based Management
This chapter delivers a detailed presentation of PoE+ Managed Injector Hub’s functionalities and allows you
to manage the PoE+ Managed Injector Hub with ease.
Figure 4-1: Main Web Page
■ Main Menu
The main menu displays the product name, function menu, and main information in the center. Via the Web
management, the administrator can set up the device by selecting the functions those listed in the function
menu and button as shown in Figures 4-2 and 4-3.
Figure 4-2: Function Menu
Main Menu
Object Description
System
Provides system information of the PoE+ Managed Injector Hub.
Network
Provides LAN and network configuration of the PoE+ Managed Injector Hub.
Security
Provides firewall and security configuration of the PoE+ Managed Injector Hub.
PoE
Provides PoE Management configuration of the PoE+ Managed Injector Hub.
Maintenance
Provides firmware upgrade and setting file restore/backup configuration of the
PoE+ Managed Injector Hub.
Figure 4-3: Function Button
