The screen in Figure 4-4-4 appears.
Figure 4-4-4: PoE Schedule Screenshot
Please press Add button to start setting PoE Schedule function. You have to set PoE schedule to profile and
then go back to PoE Port Configuration, and select Schedulemode from per port PoE Modeoption to
enable you to indicate which schedule profile could be applied to the PoE port.
The page includes the following fields:
PoE Schedule
Object Description
Profile
Set the schedule profile mode. Possible profiles are:
Profile1
Profile2
Profile3
Profile4
Week Day
Allows user to set week day for defining PoE function by enabling it on the day.
Start Hour
Allows user to set what hour PoE function does by enabling it.
Start Min
Allows user to set what minute PoE function does by enabling it.
End Hour
Allows user to set what hour PoE function does by disabling it.
End Min
Allows user to set what minute PoE function does by disabling it.
Reboot Enable
Allows user to enable or disable the whole PoE port reboot by PoE reboot schedule.
Please note that if you want PoE schedule and PoE reboot schedule to work at the same
time, please use this function, and don’t use Reboot Only function. This function offers
administrator to reboot PoE device at an indicated time if administrator has this kind of
requirement.
Reboot Only
Allows user to reboot PoE function by PoE reboot schedule. Please note that if
administrator enables this function, PoE schedule will not set time to profile. This function
is just for PoE port to reset at an indicated time.
Reboot Hour
Allows user to set what hour PoE reboots. This function is only for PoE reboot schedule.
Reboot Min
Allows user to set what minute PoE reboots. This function is only for PoE reboot schedule.
Table 4-4-3: Descriptions of the PoE Schedule Objects Screen
