2.Tightenthewire-clampscrewstopreventthewiresfromloosening.
1 2 3 4 5 6
Power 1 Alarm Power 2
+ - + -
Figure 3-3: The screws of 6-contact terminal block connector
Thewire gauge ofthe terminal blockshould be between12 and
24AWG.
