Planet IPX-2500 - Changing IP Address or Forgotten Admin Password

14
Step 2. Edit your ETH port IP information.
There are three types of Ethernet port connection. They are Static IP, PPPoE
(Point-to-PointProtocoloverEthernet), DHCP.Youcannddetailedsettingprocess
in the user manual.
Selection of IP Connection Type
2.3.3 Changing IP Address or forgotten admin password
To reset the IP address to the default IP Address “192.168.0.1” (ETH) or reset the
login password to default value. Press the reset button on the front panel for more
than 6 seconds.Afterthedeviceisrebooted,youcanloginthemanagementWEB
interface within the same subnet of 192.168.0.xx.
Reset Button
Console ETH
Reset
12V DC
Note
Afterpressing the“Reset”button,all the system data will bereset
todefault;ifpossible,backuptheconfigfilebeforeresetting.
