4.2 ConguringIPAddress
TheManagedMetroSwitchisshippedwithdefaultIPaddressshownbelow.
IPAddress:192.168.0.100
SubnetMask:255.255.255.0
To check the current IP address or modify a new IP address for the Switch,
pleaseuse theproceduresasfollows:
ShowingtheCurrentIPAddress
1.Atthe“#”prompt,enter“show ip interface brief”.
2.ThescreendisplaysthecurrentIPaddressasshown inFigure4-6.
Figure 4-6: IP Information Screen
ConguringIPAddress
3.At the “#” prompt, enter the following command and press <Enter> as
shown in Figure 4-7.
MGSW-28240F#congureterminal
MGSW-28240F(cong)#interfacevlan1
MGSW-28240F(cong-if-vlan)#ipaddress192.168.1.100 255.255.255.0
Figure 4-7: Conguring IP Address Screen
