Tighten the wire-clamp screws for preventing the wires from loosening.

1 2 3 4 5 6

V1+ V1- V2+ V2-

Power 1 Power 2

Positive(+)Pin Negative(-)Pin

ManagedMetroSwitch Pin1/5 Pin2/6

The wire gauge for the terminal block should be in the range

from 12 to 24AWG.
