Planmeca Ethernet interface 21
TECHNICAL SPECIFICATIONS
Installation manual
8 TECHNICAL SPECIFICATIONS
Planmeca Ethernet interface
Ethernet interface box
dimensions 198 x 178 x 36 mm (7.80 x 7,00 x 1.42 in.)
Ethernet cable RJ45 cable, max. 100 m (328 ft.)
Electrical classification Class I, type BF
Power supply Type: Mascot 9920/12/3617
Input voltage 100-240 VAC (50-60 Hz)
Output voltage 12VDC...13.2VDC +-5%
Max. output current> 1A
Insulation voltage
Primary-secondary4000 VAC / 5640 VDC
Plug
ø2.5mm
ø5.5mm
