Plantronics CS510 - Headset Set Up; Adjust the Headband; Adjust the Mouthpiece

7 7
Headset Set Up
Your headset comes fully assembled. You can adjust the headband for a bet-
ter fit and the mouthpiece for optimal performance.
Adjust the Headband
1 To adjust the headband, lengthen or shorten the band until it fits comfortably. The clickstop
feature keeps the headband securely adjusted.
2 Position the headset so that the foam ear cushion(s) sit comfortably over the center of your
ear(s). For the C510 headset, position the stabilizer T-bar above your ear.
3 For a tighter fit, gently pull the opposite end of the headset inward as shown.
Adjust the Mouthpiece
1 Carefully bend and shape the boom with both hands as shown. Avoid bending or twisting the
boom near the microphone or earpiece.
2 Position the click stop turret and boom so that the microphone is two finger-widths from the
corner of your mouth.
2"
50.8
mm
front back
2"
50.8
mm
front back
