3
STEP 2. CONNECT MC500 MEDIA PLAYER TO YOUR SOUND
SYSTEM
Connect an RCA audio cable to the Zone 1 Output (L) on the back of the MC500. Connect the opposite
end of the cable to your amplifier equipment. Repeat these steps for Zone 2 Output (M) if a second
zone is required.
ZONE 1
ZONE 2
To the Power Amplifier
STEP 3. ATTACH THE POWER CORD
Find the surge protector and external power supply (included) and plug them together. Next, plug one
end into the Power Inlet (I) on the back of the player. Then plug the external power supply into the
surge protector provided. Finally, plug the surge protector into your wall outlet. Use only 120VAC 60 Hz
power.
To Next Page
