31
L510001-05
Figure 5-3 Throttle Position Setting
OPERATING INSTRUCTIONS - 5
NOTICE: If engine still fails to start, contact your
Crusader Marine Engines Dealer for service.
8. Check engine oil pressure immediately after
the engine starts. If oil pressure is not
within specifi cations (see Engine Specifi cations),
immediately stop the engine and determine the
cause.
9. Check voltmeter for proper charging system
operation.
10. Check the engine and transmission for fuel, oil,
water and exhaust leaks.
11. Allow the engine to reach normal operating
temperature. Check the temperature gauge
to ensure the engine is operating within the
normal temperature range. If the temperature
is abnormally high, stop the engine immediately
and determine the cause.
SHIFTING TRANSMISSION
CAUTION
Never shift the transmission into or out of gear
unless the throttle is at the idle position. Shifting the
transmission above 1000 RPM can severely damage
the boat, transmission and engine.
1. Set the throttle lever at the idle position.
2. Move the transmission lever completely forward
to shift into Forward gear.
3. Move the transmission lever completely
backward to shift into Reverse gear.
4. Move the transmission lever to the center detent
position to shift into Neutral.
Figure 5-4 Shift Control
FULL
THROTTLE
(WOT)
CLEAR
FLOOD
(100%)
STARTING
OR IDLE
POSITION
NEUTRAL
FORWARD
GEAR
REVERSE
GEAR
