When you get ready to plant your small seeds, simply
Swing the cultipacker over behind the unit and attach the
chain/springs on the bottom of the wheel assembly to the hooks
on the cultipacker provided. In this position, the cultipacker is
used to compress soil and to roll over smaller seeds to ensure a
firm seed bed. This also ensures the seeds are not buried too
deep.
Additional downward pressure and compaction can be
obtained by connecting the hooks on the cultipacker to the
chain links that are nearer to the wheel assembly. Pressure can
be adjusted by hooking different chain links to the J-hooks.
IMPORTANT: KEEP YOUR HANDS AND FINGERS CLEAR
WHEN RAISING AND LOWERING THE DRAG AND/OR
CULTIPACKER TO AVOID PINCHING!!!
L. SET BOLT : See diagram or description in section “B”.
M. The Plotmaster™ is shipped with the wheels strapped to the
pallet. To attach the wheels to the WHEEL ASSEMBLY,
insert the square tubing of each wheel into the tubing of the
wheel assembly and secure with the 2-3/8” x 3-1/2” bolts
shipped in the plastic bag located in the seed box. Tighten the
nylock nuts securely.
N. METAL GRATING. See diagram or description in section “J”
OTHER ATTACHMENTS:
COMPACTOR: This attachment is used to compact soils and
prepare a smooth seed bed prior to planting small seeds such as
clover or grass seed. This is an important step to ensure that
these small seeds are not planted too deep. Small seed such as
chicory and clover should never be planted more than 1/4”
deep.
SCRAPE BLADE: This attachment is used to level the soil,
scrape driveways and has been used to remove manure from
goat pens and chicken houses. The uses are endless.
