Fusion process Operating Instructions MSA 2 CF
10
2 Fusion process
2.1 Overview of operating procedure
The welding workflow is shown in the picture below
t = ----s
Vo= --.-V
R = --.--Ω
12/06/19 15:50 70°F
t = ----s
Vo= --.-V
R = 07.45Ω
------
------
12/06/19 15:50 70°F
t = 0040s
Vo= 39.5V
R = 07.45Ω
12/06/19 15:50 70°F
t = 0020s
Vo= 39.7V
E = 003.1kJ
N 150
t = 0040s
Vo= 39.6 V
E = 007.5kJ
N 150
 = 10’
N 150
Prepare the
welding and
connect the fitting
Read the fusion
parameters
barcode
Start the fusion
Fusion in progress
Fusion completed
automatically
Cooling time

+GF+ MSA 2 CF Specifications

General

Brand	+GF+
Model	MSA 2 CF
Category	Welding Accessories
Language	English
