+GF+ MSA 2 CF User Manual

Operating Instructions MSA 2 CF Data Management
21
4 Data Management
The electro-fusion unit saves the welding protocols for each
fusion cycle in the internal memory. For MSA 2 CF these data
can be saved in a PDF/BINARY.
When the memory is full, the oldest protocol is overwritten by the
most recent.
To conform to different standards, the welding machine saves
(and provides for a later analysis) the following data:
MSA Type & Serial Number
MSA 2 CF S156H7001007
Fusion cycle number
Date/time of fusion cycle
Error number
Fitting size
Fitting type
Fitting manufacturer
Fusion voltage nominal
Fusion time nominal
Fusion preparation verified
Fusion voltage actual
Fusion time actual
Energy
Mains voltage
Ambient temperature
Operator code (only inside .BIN)
Job number (only inside .BIN)
Cooling time (only inside .BIN)
