10
X50 / X100
1. Scan Indicator: Indicates the scanner’s scan status. The scanner will beep and the
scan indicator will blink when the scan process is finished.
Light Status
Blinking
The scanner has completed the scanning task. It also comes with
a beep sound.
Off The scanner currently is not scanning.
2. Power Indicator: Indicates the scanner’s power status.
Light Status
On The scanner is turned on, ready to scan images.
Off The scanner is off.
3. Scanner Glass: Where you put items for scanning.
4. Alignment Bar: Always align the edge of your document to this bar. You may
adjust the bar to place it next to the right or left side of the scanner glass.
5. Cover: Install the cover onto the scanner to avoid the scanned image’s dark
background caused by the ambient light in the room.
