PMC result6 - System Description Overview

System description
Balanced XLR
analogue input
RFI & EMI
filtering
Level trim
+/- 10dB
Dual-band
power limiter
Active analogue
24dB-per-octave
crossover
Non-invasive
driver protection
sensor
Non-invasive
driver protection
sensor
65W HF power
amplifier
100W LF power
amplifier
Audio enters the result6 via a balanced, low-
noise, low-distortion analogue input, and
the signal path through the loudspeaker
and independent power amplier has been
designed to be as short as possible to maintain
these qualities throughout.
A total of 165W of high-efciency amplication
is provided, with 65W for the high-frequency
driver and 100W for the bass unit. The amplier
design ensures that driver impedance variations
with frequency are fully compensated to
maintain a uniform frequency response.
