TECHNICAL INFORMATION
Frequency: 344.04 Megahertz
Transmit output power: Less than 0.001 watt (1/1000 of a watt or 1 milliwatt)
Minimum receive Contact Time: 80 milliseconds
Maximum Frames Per Second: 12
Top Ports: 3.5mm (1/8") mono miniphone
CAMERA / FLASH Port Voltage Handling: up to 100 Volts
FLASH Port Voltage Handling: up to 200 Volts
CAMERA / FLASH = center positive; FLASH = non-polarized
Both ports are current limited: 4 Amp peak, 250 millamp continuous
CAMERA / FLASH Port and hot shoe mount voltage present: 3.3 Volts DC.
A camera is protected from a flash connected to either port.
AC Adapter jack: 3V DC 200mA (unregulated), Center Positive
Male plug connector required: 1.3mm ID, 3.4mm OD, 1cm long
Body Dimensions: 1.4" deep x 2.1" wide x 4" tall
Antenna: 2.4" tall, 0.3" diameter
Weight: Less than 5 ounces with alkaline batteries
Operating temperature: above -15° C (5° F) and below 50° C (120° F)
Storage temperature, without batteries: above -30° C (-22° F) and
below 85° C (185° F)
