POCKETWIZARD PLUS II PART REFERENCE
Lanyard Loop
Flash
Camera / Flash
Status LED
On/Off
Switch
Locking Hot
Shoe Mount
Battery
Door
1
/
4
- 20
Mount
Battery Door Latch
Flexible Antenna
Status LED
TRANSMIT MODE
Local/Both/Remote
AC
Power
Test
Button
Channel
Selection
PC1 Cable
For use with a
camera’s PC terminal
AA Batteries
(IEC-LR6)
Lanyard
VELCRO
®
Adhesive Hook
and Loop Fasteners
