40
THE PERFECT FIT
IQ Front Suspension Adjustments
WARNING! Always verify ski alignment before making adjustments to the IFS.
See page 98 to check alignment. If the skis are misaligned, see your dealer, as
the camber adjustment may also be affected.
Standard Shocks
The tension at which the shock coil spring is set is called spring preload.
For the best ride, the suspension should be adjusted to use the full travel
of the shocks with occasional light bottoming.
The front springs can be changed if spring preload alone isn't sufficient
and further adjustment is desired to control suspension stiffness. See
your Polaris dealer for more information.
Shock Absorber Components
1. Retainer
2. Jounce Bumper
3. Shock Rod
4. Body
5. Threaded Spring Preload Adjuster Nut
6. Spring (Standard only)
