124
SPECIFICATIONS
800 SWITCHBACK
Capacities and Dimensions
Body Style PRO-RIDE
Rider Capacity 1
Coolant Capacity 5 qts. (4.7 l)
Chaincase Oil Capacity 9 oz. (266.2 ml)
Fuel Tank Capacity 11 gal. (41.6 l)
Gearcase Oil Capacity (oz./ml) N/A
Oil Capacity (qts./l) 3.8 qts. (3.6 l)
Height 46 inches (117 cm)
Length 115 inches (292 cm)
Designed Width (in./cm) 48 inches (122 cm)
Brake Type Hayes Phantom
Drive Clutch Center Distance 11.5 inches (29 cm)
Drive Belt P/N 3211115
Clutch Type P-85
Reverse Transmission Electronic Reverse
Engine and Cooling
Engine S4774-8044-OR8G
Displacement 794 cc
Cylinders 2-Monoblock
Bore x Stroke (mm) 85 x 70
Alternator Output 400 watt
Throttle Body Mikuni
Oil Injection VES
Throttle Body Bore Size 48 mm
Idle RPM 1700 +/- 200
Cooling Liquid
Ignition Type Digital
Ignition Timing 18° @ idle 1700 RPM w/120°F (49°C) water temp
Spark Plug / Gap NGK BPR9ES /.027 inches (0.7 mm)
Recommended Fuel Octane 91 Recommended (87 Minimum)
