Polaris 800 RMK User Manual

104
MAINTENANCE
Clutch System
Drive Belt Installation
1. With the L-wrench inserted into
the threaded hole and the sheaves
in the open position, install the
drive belt.
TIP:Install the belt so that the numbers
can be read correctly on the left side
of the vehicle, or in the direction in
which the belt was originally
installed.
2. Wiggle the belt to remove slack
while removing the L-wrench.
3. Reinstall the side panel.
4. Break in the new belt. See page 67.

Polaris 800 RMK Specifications

General

Bore x Stroke	85 mm x 70 mm
Engine Stroke	2-Stroke
Rear Suspension	RMK Adjustable
Track Width	15 inches
Track Length	155 in (393.7 cm) / 163 in (414 cm)
Track Height	2.4 inches
Fuel Capacity	11.5 gallons
Engine	Liberty 800
Rear Travel	16 in (40.6 cm)
Displacement	794cc
