Polaris 800 RMK User Manual

95
MAINTENANCE
Drive Chain Tension (RMK/ASSAULT RMK)
Check drive chain tension weekly and before each long trip.
1. Remove the side panels.
2. Rotate the driven clutch
counter-clockwise to move all
chain slack to the tensioner
side. Lock the brake lever
lock, or have an assistant hold
the brake lever firmly.
3. Loosen the adjuster bolt jam
nut.
4. Finger tighten the adjuster bolt
until it can no longer be
adjusted by hand, then back
off 1/4 turn.
5. Tighten the jam nut while
holding the adjuster bolt.
Torque to 21 ft. lbs. (28 Nm).
6. Reinstall the side panels.
7. Release the brake lever lock.
Jam
Nut
Adjuster
Bolt

Polaris 800 RMK Specifications

General

Bore x Stroke	85 mm x 70 mm
Engine Stroke	2-Stroke
Rear Suspension	RMK Adjustable
Track Width	15 inches
Track Length	155 in (393.7 cm) / 163 in (414 cm)
Track Height	2.4 inches
Fuel Capacity	11.5 gallons
Engine	Liberty 800
Rear Travel	16 in (40.6 cm)
Displacement	794cc
