69
THE PERFECT FIT
Suspension Quick Set-Up Guide
Front Track Shock Spring Settings
Factory settings, combined with user adjustments to the rear track shock
spring (RTSS), should be all that’s necessary to provide the best riding
experience for most riders. The primary adjustment for overall vehicle
balance is RTSS preload. Perform this adjustment first.
Always perform shock spring preload adjustments with the weight of the
vehicle removed from the shock and with the shock at full extension.
NOTICE: Never adjust spring preload to an installed length longer than the
factory length or shorter than the minimum length as shown in the
following chart. Damage to the suspension could result. When
decreasing preload, make sure at least two turns of preload are
holding the retainer against the spring.
Factory Spring Maximum Installed
Length
Minimum Installed
Length
RMK 8.375" (21.3 cm) 8.2" (20.8 cm)
PRO-RMK 8.375" (21.3 cm) 8.2" (20.8 cm)
ASSAULT RMK 8.375" (21.3 cm) 8.2" (20.8 cm)
Installed Length
Measurement
