THE PERFECT FIT
Suspension Quick Set-Up Guide
Rear Track Shock Spring Settings
NOTICE: Do not install accessory bogie wheels on the inside of the rail beams if
your model is equipped with a remote reservoir rear track shock or
damage will occur. The rail scratchers must first be removed as they
interfere with the accessory bogie wheels.
Rear Track Shock Factory Clicker Settings
Initial RTS Shock Preload Settings
(Measure spring length with suspension off the ground)
Rider Weight Model Factory
Installed Length
Minimum
Installed
Length
For Factory-Installed Springs
< 160 lbs. < 73 kg SKS/PRO-RMK 10.75" 27.3 cm
9.8"
(24.9 cm)
ASSAULT RMK 10.75" 27.3 cm
160-220 lbs 73-100 kg SKS/PRO-RMK *10.5" *26.7 cm
ASSAULT RMK *10.5" *26.7 cm
220-280 lbs. 100-127 kg SKS/PRO-RMK 10.125" 25.7 cm
ASSAULT RMK 10.125" 25.7 cm
280-340 lbs. 127-154 kg SKS/PRO-RMK 9.8" 24.9 cm
ASSAULT RMK 9.8" 24.9 cm
*Factory Setting
For Optional 250 lb./in. Stiff Springs (see your dealer)
250-300 lbs. 113-136 kg ALL 10.25" 26 cm 10"
(25.4 cm)
300-350 lbs. 136-159 kg ALL 10" 25.4 cm
Model Clicker Setting
(from full soft)
SKS 3
PRO-RMK w/clicker 3
RMK ASSAULT 6
