25
FEATURES AND CONTROLS
Trailer Receiver Hitch Bracket
This vehicle is equipped with a receiver hitch bracket for a trailer hitch.
Trailer towing equipment is not supplied with this vehicle.
To avoid injury and property damage, always heed the warnings and
towing capacities outlined on pages 60-62.
Service Access Panels
Access serviceable engine components through the engine access panel
behind the seat. Remove the seat and release the access panel latches to
remove the access panel.
Remove the rear access panel to access the air box, oil fill cap and spark
plugs. The rear access panel is located in the bed of the cargo box. Pull
the rear edge of the access panel upward to remove it.
Radiator Access/Bumper Removal
The front bumper can be
removed to clean debris from
the radiator.
1. Remove the four (4) torx
screws and six (6) plastic
rivets.
2. Lift the front bumper to
remove it from the vehicle.
